This is called Application button by clicking it we will be able to see the option for creating and using the files.ĪUTODESK INVENTOR 2015 TUTORIAL FOR BEGINNERS SOFTWARE.
You can say basic file operation function are available here.
Here also the recently used file are displayed.
This is called Quick Access Toolbar where frequently used operations can be found.
Here also you can add additional items according to your preference.
These are tabs where different types of tools are grouped.
For an example in this 3D modeling Tab most frequently used features and operation like,2D or 3D sketch, Extrude, Revolve, Sweep Loft, Fillet, Holes etc.
In the same way there are other tabs like sketching, Inspect, Tools, Manage View Environment, etc.
That are used time to time and other tabs that are automatically active when we use specific operations.
In the tab specified tools are grouped in the panels.
In these panels where you see an arrow click it to expand it to find additional tools.
There are additional panel which can be added also.
This is the Help and command Search box form where you can search for help online/offline and specified tool location in the software.
This is View Cube which manipulate the view of the model so that you can rotate your design and position it based on the standard views.
This is Navigation Bar which offers tools like Full Navigation Wheel, Pan, Zoom, Free Orbit, Look at tools and additionally you can add more tools.
The center area is called design window where sketches and 3D model is displayed.ĪUTODESK INVENTOR 2015 TUTORIAL FOR BEGINNERS FULL.
This place is called Status Bar which provides useful help related to the activities performed in the software.
Here is our Browser Bar which contains name of the active file, origin folders, Representations and part features modeling history.
Add an additional Panel named Primitives if it is not present.
Draw a sketch coincident with the origin along with dimension displayed.
